Acetate Cloth FFC Cable Assembly Including ZIF Zero Insertion Force Connector Type Gray Flat Flexible Cable Suitable for Electronics

Product Description:

The Flat Ribbon Cable Assembly is an essential component designed to meet the diverse connectivity needs of modern electronic devices. Engineered with precision and flexibility in mind, this cable assembly offers a reliable and efficient solution for various applications, ranging from consumer electronics to industrial equipment. One of the standout features of this Flat Ribbon Cable Assembly is its customizable thickness, allowing users to tailor the cable to specific requirements and ensuring optimal performance in different environments and configurations.

Constructed to comply fully with RoHS standards, the Flat Ribbon Cable Assembly guarantees that it is environmentally friendly and free from hazardous substances. This compliance not only ensures safety during usage but also aligns with global regulations aimed at reducing electronic waste and promoting sustainable manufacturing practices. The commitment to RoHS compliance makes this cable assembly an excellent choice for companies and consumers who prioritize eco-conscious products without compromising on quality or functionality.

The Flat Ribbon Cable Assembly is designed without shielding, which allows for a lightweight and flexible structure. This lack of shielding helps in reducing the overall thickness and weight of the cable, making it easier to install in tight spaces and complex assemblies. Despite the absence of shielding, the cable maintains excellent electrical performance, particularly due to its precise impedance characteristics. With a characteristic impedance of 90 Ω, this cable assembly is ideal for high-speed data transmission, minimizing signal reflection and ensuring integrity across connections.

Visually, the Flat Ribbon Cable Assembly features a sleek gray color that not only provides a professional and clean appearance but also aids in easy identification during assembly or maintenance processes. The neutral gray color blends well with other components and wiring harnesses, contributing to an organized and aesthetically pleasing electronic setup. This color choice reflects a balance between functionality and design, catering to both technical and practical considerations.

One of the significant advantages of this Flat Ribbon Cable Assembly is its versatility. The customizable thickness option enables engineers and designers to adapt the cable to various thickness requirements, enhancing compatibility with different device architectures and ensuring durability where space constraints or mechanical stresses are factors. This adaptability makes the Flat Ribbon Cable Assembly suitable for a wide range of industries, including telecommunications, automotive, medical devices, and consumer electronics.

Furthermore, the precise 90 Ω characteristic impedance plays a crucial role in the cable’s effectiveness in transmitting signals with minimal loss and distortion. This impedance level is particularly critical in applications involving high-frequency signals, where maintaining signal integrity is paramount. The cable’s design ensures that it supports consistent electrical performance, which is vital for maintaining the reliability and efficiency of connected systems.

In summary, the Flat Ribbon Cable Assembly combines customizable physical properties with stringent compliance and superior electrical characteristics to deliver a product that meets the demanding requirements of modern electronic applications. Its RoHS compliance ensures environmental safety, while the absence of shielding enhances flexibility and ease of installation. The characteristic impedance of 90 Ω guarantees optimal signal transmission, and the gray color offers a professional and unobtrusive appearance. Whether used in complex industrial machinery or compact consumer gadgets, this Flat Ribbon Cable Assembly provides a dependable, adaptable, and efficient cabling solution that stands out in both performance and design.

Features:

• Product Name: FFC Cable Assembly
• Packaging Method: Packed In Cartons
• Width: Customizable to fit various requirements
• Connector Type: ZIF (Zero Insertion Force) for easy and reliable connections
• Application: Ideal for interconnecting electronic components in compact devices
• RoHS Compliant: Yes, ensuring environmentally friendly manufacturing
• Flat Ribbon Cable Assembly designed for efficient space utilization
• Flat Ribbon Cable Assembly offers flexibility and durability in electronic assemblies
• Flat Ribbon Cable Assembly supports high-density and compact device interconnections

Technical Parameters:

This Flat Ribbon Cable Assembly offers customizable width and thickness to suit various applications. The Flat Ribbon Cable Assembly is designed with a 30V voltage rating and can operate within a temperature range of -20°C to 80°C. Featuring nickel plated pin materials and a current rating of 1A, this Flat Ribbon Cable Assembly ensures reliable performance. The ZIF (Zero Insertion Force) connector type and characteristic impedance of 90 Ω make it ideal for precise connectivity needs. Cable lengths range from 50mm to 15000mm, constructed from FFC, acetate cloth, and double-sided tape materials.

Applications:

The Flat Ribbon Cable Assembly is widely used across various industries due to its customizable width and versatile cable length, ranging from 50mm to 15000mm. This adaptability makes it an ideal solution for numerous application occasions and scenarios where space constraints and precise connectivity are critical. Whether in compact electronic devices or large-scale industrial equipment, the Flat Ribbon Cable Assembly provides reliable and efficient connections.

One common application scenario for the Flat Ribbon Cable Assembly is in consumer electronics such as laptops, printers, and cameras. Its flat design allows for easy routing through tight spaces without causing interference or bulkiness. The customizable width ensures that the cable can accommodate different pin counts and connector configurations, making it suitable for various device models. Additionally, the ZIF (Zero Insertion Force) connector type simplifies the connection process by allowing easy insertion and removal without damaging the delicate contacts, which is particularly important in devices requiring frequent maintenance or upgrades.

In industrial settings, the Flat Ribbon Cable Assembly is frequently employed in automation systems, control panels, and machinery where long cable runs are necessary. The cable length customization from 50mm up to 15000mm ensures that it can meet the demands of complex installations. Moreover, the operating temperature range of -20°C to 80°C guarantees stable performance even in harsh environments, such as manufacturing plants or outdoor installations where temperature fluctuations are common. The packaging method, which involves packing the cables in cartons, ensures safe transportation and storage, preventing damage prior to installation.

Medical equipment is another critical area where the Flat Ribbon Cable Assembly excels. Devices such as diagnostic machines, patient monitors, and imaging systems benefit from the cable’s flexibility and reliability. The flat ribbon design minimizes electromagnetic interference, ensuring accurate signal transmission essential for medical applications. Furthermore, the ZIF connector type reduces wear and tear during assembly and maintenance, extending the lifespan of the equipment.

In summary, the Flat Ribbon Cable Assembly is perfectly suited for a wide range of application occasions and scenarios including consumer electronics, industrial automation, and medical devices. Its customizable width, extensive cable length options, robust operating temperature range, and user-friendly ZIF connectors make it a versatile and dependable choice for any project requiring efficient and durable cable connections.
